Recirculating Coolers

Chiller (Recirculating Coolers) (Low Temp. General)

Powerful recirculating coolers.

Provide a wide range of cooling capacities with temperature reliability.

Model Name : HL-05/10/15/15H/20/20H/25H/35H/45H/55H


BROCHUREURL COPYInquiry Form

Performance

  • Temperature range from -20°Cto 40°C.
  • High cooling capacity up to 7.1kW at 20°C.
  • Powerful circulating pumps up to70L/min., 6 bar.
  • Refrigerating system is designed to reduce energy consumption and maximize refrigerating efficiency.

Convenience

  • Designed to simplify operation with a touch screen type display.
    - Easy-to-read VFD display with interactive touch keys.
    - Setting and resolution indication 0.1°C/°F.
    - Quick keypad lock prevents accidental parameter changes.
    - Signal indicator for operation status.
  • Bright LED water level indicator can be seen from a distance.
  • Built in pressure gauge for checking pump pressure at a glance.
  • High/low pressure gauges for condition diagnosis of refrigerating system at a glance. (for H type)
  • Wide filling inlet for easy and safe pouring of solution into the unit.
  • Double service valve prevents refrigerant leakage for easy maintenance.
  • Removable gridded vent for easy maintenance of condenser.
  • Built-in casters for easy transport and installation.

Safety

  • Self-diagnostic function identifying errors.
  • Complete safety protection system with warning alarms.
    - Low fluid level and dry-running protection; when triggered shows an error symbol on the display and an audible buzzer sound.
    - Over-temperature protection; If the equipment operates at over maximum temperature due to external environment, user can simply identify the error with a visual signal or an audible buzzer sound.
    - Over-current circuit breaker.
  • Eco-friendly R-404A / R-507 refrigerant use for environmental protection.
  • Splash-proof keypad.



Model HL-05 HL-10 HL-15 HL-20 HL-15H HL-20H HL-25H HL-35H 2)HL-45H 2)HL-55H
Temperature 1)
(bath fluid : ethylene glycol mix 1:1 water)		 Working temp. range (℃ / ℉) -20 to 40 / -4 to 104
Temp. stability at15℃, (±℃ / ℉) 1 / 1.8
Cooling capacity
(bath fluid : ethylene glycol mix 1:1 water)		 at 20℃ (kw) 0.6 0.7 1.45 1.8 1.45 1.8 2.5 3.3 6.5 7.1
at 10℃ (kw) 0.5 0.6 1.15 1.5 1.15 1.5 1.8 2.3 4.5 6
at 0℃ (kw) 0.35 0.42 0.86 1.15 0.86 1.15 1.1 1.7 3 4.1
at -10℃ (kw) 0.18 0.32 0.62 0.85 0.62 0.85 0.65 1 2.1 2.5
at -20℃ (kw) 0.04 0.14 0.3 0.40 0.3 0.4 0.4 0.55 1.2 1.5
Pump

Max. flow rate

(L / min, gal / min)

 50 / 13.2 40 / 10.57 70 / 18.49

Max. pressure

(bar / psi)

 1 / 14.5 3.3 / 47.9 6 / 87
Dimension

Max,. filling Capacity

(L, cu ft)

 7.5 / 0.26 13.5 / 0.47 25 / 0.88 39 /1.37

For tubing dia.

(mm / inch)

 20 / 3/4

Filling inlet

(Ø, mm / inch)

 120 / 4.7

Overall

(WxLxH, mm / inch)

405×620×710

/15.9×24.4×28

515×715× 835

/20.3×28.1×32.9

550×900×1140

/21.7×35.4×44.9

605×1045×1300

/23.8×41.4×51.2

Net weight

(kg / Ibs)

62.85

/138.6

64.85

/143

86.5

/190.7

87.35

/192.9

91.8

/202.4

92.65

/204.3

141.3

/310.9

146.3

/321.9

171±10

/377±22

176±10

/388±22

Electric requirement (230V, 60Hz) 5A 5.5A 6.5A 7.5A 6.5A 7.5A 9.5A 13.5A
Cat. No.

AAH65001K

AAH65011K

AAH65021K

AAH65031K

AAH65121K

AAH65131K

AAH65141K

AAH65151K

 - -
Electric requirement (230V, 50Hz) 4.5A 5A 6A 7A 6A 7A 7.5A 12.5A
Cat. No.

AAH65005K

AAH65015K

AAH65025K

AAH65035K

AAH65125K

AAH65135K

AAH65145K

AAH65155K

 - -
Electric requirement (120V, 60Hz) 10A 11A 13A 15A
Cat. No.

AAH65003U

AAH65013U

AAH65023U

AAH65033U

 - - - - - -
Electric requirement (380V, 60Hz) 5.5A 7A
Cat. No. - - - - - - - -

AAH65169K

AAH65179K

Electric requirement (380V, 50Hz) 5A 6A
Cat. No. - - - - - - - -

AAH65160K

AAH65170K

1) Technical data according to DIN 12876.
2) HL-45H, 55H is recorded by 380V, 60Hz.
※ Above specification value is recorded by 50Hz.
※ Product performance may be affected by ambient temperatures.
※ CE except for HL-45H/55H.



Barbed fittings

Geared for quick connecting of various size type tubes using pipe fittings, tube fittings, and hose fittings without tools.

Barbed fittings

Cat. No. Description
00HXE0001066 3/4" male to barbed fitting for tubing 1" inner dia.
00HXE0001067 3/4" male to barbed fitting for tubing 3/4" inner dia.
00HXE0001068 3/4" male to barbed fitting for tubing 5/8" inner dia.
00HXE0001069 3/4" male to barbed fitting for tubing 1/2" inner dia.
00HXE0001070 3/4" male to barbed fitting for tubing 3/8" inner dia.
AAA64501 1" barbed fittings set with ball valve
AAA64502 3/4" barbed fittings set with ball valve
AAA64503 5/8" barbed fittings set with ball valve
AAA64504 1/2" barbed fittings set with ball valve
AAA64505 3/8" barbed fittings set with ball valve
AAA64506 1" barbed fittings set with gate valve
AAA64507 3/4" barbed fittings set with gate valve
AAA64508 5/8" barbed fittings set with gate valve
AAA64509 1/2" barbed fittings set with gate valve
AAA64510 3/8" barbed fittings set with gate valve

Connectors / Adapters

Connect tubing or other devices.

Connectors / Adapters

Cat. No. Description
00HXE0001105 3/4" male to 3/4" female
00HXE0001106 3/4" male to 5/8" female
00HXE0001107 3/4" male to 1/2" female
00HXE0001108 3/4" male to 3/8" female
00HXE0001109 3/4" male to 3/4" male
00HXE0001110 3/4" male to 5/8" male
00HXE0001111 3/4" male to 1/2" male
00HXE0001112 3/4" male to 3/8" male

One touch adapters set

Convenient to connect and exchange tubing.

One touch adapters set

Cat. No.
 Description
00HXE0001075
 12mm one touch adapter ID. 9mm, OD. 12mm
00HXE0001076
 10mm one touch adapter ID. 6.5mm, OD. 10mm
00HXE0001077
 8mm one touch adapter ID. 5.5mm, OD. 8mm
00HXE0001078
 6mm one touch adapter ID. 4mm, OD. 6mm
AAA64531
 12mm adapters set with ball valve
AAA64532
 10mm adapters set with ball valve
AAA64533
 8mm adapters set with ball valve
AAA64534
 6mm adapters set with ball valve

Flexible fittings

Stainless steel tubing designed for superior flexibility and with good chemical resistance.

Flexible fittings

Cat. No. Description
00GBA0008589 3/4" male to 3/4" flexible fitting
00HXE0001072 3/4" male to 1/2" female with 1/2" male to 1/2" flexible fitting
AAA64521 3/4" flexible fittings set with ball valve
AAA64522 1/2" flexible fittings set with ball valve
AAA64523 3/4" flexible fittings set with gate valve
AAA64524 1/2" flexible fittings set with gate valve

Tubings

Excellent heat resistance and corrosion resistance urethane tubing.

Tubings

Cat. No. Description
00HXE0001079 1m 12mm urethane tubing ID. 9mm, OD. 12mm
00HXE0001080 1m 10mm urethane tubing ID. 6.5mm, OD. 10mm
00HXE0001081 1m 8mm urethane tubing ID. 5.5mm, OD. 8mm
00HXE0001082 1m 6mm urethane tubing ID. 4mm, OD. 6mm
00HXE0001083 1m 1" PVC tubing with thread ID. 25mm, OD. 31mm
00HXE0001084 1m 3/4" PVC tubing with thread ID. 19mm, OD. 24mm
00HXE0001085 1m 5/8" PVC tubing with thread ID. 16mm, OD. 20.5mm
00HXE0001086 1m 1/2" PVC tubing with thread ID. 12mm, OD. 16.0mm
00HXE0001087 1m 3/8" PVC tubing with thread ID. 10mm, OD. 14mm
00HXE0001088 1m 1" PVC tubing with wire ID. 25mm, OD. 33mm
00HXE0001089 1m 3/4" PVC tubing with wire ID. 19mm, OD. 26mm
00HXE0001090 1m 5/8" PVC tubing with wire ID. 15mm, OD. 22mm
00HXE0001091 1m 1/2" PVC tubing with wire ID. 12mm, OD. 18mm
00HXE0001092 1m 3/8" PVC tubing with wire ID. 9mm, OD. 15mm

Tubing insulations

EPDM insulation is used to reduce heat loss and condensation from cold water plumb- ing, chilled water, and refrigeration lines.

Tubing insulations

Cat. No.
 Description
00FEA0001453
 EPDM insulation, 25mm inner dia. (13T)
00HXE0001093
 EPDM insulation, 16mm inner dia. (9T)
00HXE0001094
 EPDM insulation, 19mm inner dia. (9T)
00HXE0001095
 EPDM insulation, 25mm inner dia. (9T)
00HXE0001096
 EPDM insulation, 28mm inner dia. (9T)
00HXE0001097
 EPDM insulation, 35mm inner dia. (9T)

Flexible tubing

Cat. No.
 Description
00HXE0001128
 3/4" flexible tubing
00HXE0001074
 1/2" flexible tubing

Tube clamps

Corrosion resistant stainless steel clamps

Tube clamps

Cat.No. Description
00HXE0001098
 1" clamp
00HXE0001099 3/4" clamp
00HXE0001100 5/8" clamp
00HXE0001101 1/2" clamp
00HXE0001102 3/8" clamp

Distributing fittings

Distributing fittings connect even with small tubes with barb fittings.

Distributing fittings

Cat. No. Description
AAA64541 3-way distributing barbed fittings set (1/4")
AAA64542 3-way distributing barbed fittings set (3/8")
