Baths & Circulators

Refrigerated & Heating Bath Circulators(Programmable)

Newly developed bath circulator with the Intelligent programmable controller.

Model Name : RW3-0525P/1025P/2025P/3025P
RW3-0535P/1035P/2035P/3035P


Intelligent program control

  • 10 programs available for temperature ramp up and dwell control.
  • 10 steps per a program and 99 hours 59 minutes per a step.
  • Stored programs are easily linkable.
  • Programs can be repeated up to 99 cycles.
  • Pre-heating and heating time are settable before program starts.

Performance

  • Temperature range.
    - RW3-35P models from -35°C to 150°C.
    - RW3-25P models from -25°C to 150°C.
  • Microprocessor PID control.
  • Three point temperature calibration / Automatic tuning / Automatic run.
  • Suitable for both internal and external bath environments due to reduced turbulence by using five-speed adjustable pump and built-in cooling coil.
    (1 to 3 steps of the pump for internal circulation and 4 to 5 steps for external circulation)

Pump Step 1 2 3 4 5
Max. pressure (psi) 0.5 1.1 2.4 4.9 5.9
Max. flow rate (L/min) 5.6 8.0 12.8 18.8 28.0

Convenience

  • Intuitive touch screen LCD controller with easy icons and logical menus.
  • Dual wait on/off timer modes. (1 min. to 99 hr. 59 min.)
  • Digital input and output control function for interlocking external devices.
  • RS-232 / USB interface for external control and data collection.
  • Corrosion-resistant, leak-proof, round-cornered, and easy-to-clean stainless steel bath with easy access drain valve.
  • Detachable condenser air-filter for easy maintenance of refrigerating efficiency.
  • Usage of CFC-free refrigerant (R-507, R-404A) and a double service valve for leakage prevention.
  • Quick-release front grill for easy cleaning of the condenser.
  • Built-in casters and side handles for easy transport and installation.

Touch LCD Controller

Safety

  • Isolated design of agitator, heater, and sensor by a baffle plate to minimize the turbulence in the bath fluid and also to protect users and samples against direct contact.
  • Temperature warning Indicator simply shows inner reservoir’s temperature by three different colors.
  • Complete safety protection system with warning alarms.
    - Low fluid level and dry-running, over-temperature, over-current.
  • Keypad lock function prevents accidental changes during operation.
  • Splash-proof keypad.

for temperature range from -25℃ to 150℃

Model RW3-0525P RW3-1025P RW3-2025P RW3-3025P

Bath volume (L / cu ft)

5 / 0.2

10 / 0.4

20 / 0.7

30 / 1.1

Working temperature range (℃ / ℉)

-25 to 150 / -13 to 302

Temperature stability 1)  (±℃ / ℉)

0.05 / 0.09

Cooling capacity 2)

(bath fluid: ethanol)

at -20℃ (-4℉), W

80

150

300

470

at 0℃ (+32℉), W

230

270

420

630

at +20℃ (+68℉), W

320

380

550

740

Refrigerator

1/3 LBP, R-507

1/3 LBP, R-507

1/2 LBP, R-404A

3/4 LBP, R-404A

Pump

(bath fluid: water)

Max. pressure

5.9 PSI (406.8 millibar)

Max. flow rate

7.4 gallons / minute (28 liters / minute)

Dimension

Bath opening / depth

(W×L, D) (mm / inch)

150x99x160

/ 5.9x3.9x6.3

211x154x180

/ 8.3x6.1x7.1

290x214x200

/ 11.4x 8.4x7.9

300x264x230

/ 11.8x10.4x9.1

Exterior (W×L×H)

(mm / inch)

308x480x733

/ 12.1x18.9x28.9

366x532x780

/ 14.4x20.9x30.7

386x602x825

/ 15.2x23.7x32.5

446x662x895

/ 17.6x26.1x35.2

Net weight (kg / lbs)

38 / 83.8

44 / 97

60 / 132.2

67 / 147.7

Electrical requirements (230V, 60Hz) 11A 11A 12.5A 13.5A
Cat. No. AAH57641K AAH57651K AAH57661K AAH57671K
Electrical requirements (230V, 50Hz) 11A 11A 12.5A 13.5A
Cat. No. AAH57642K AAH57652K AAH57662K AAH57672K
Electrical requirements (120V, 60Hz) 12.6A 12.6A
Cat. No. AAH57643U AAH57653U - -


for temperature range from -35℃ to 150℃

Model RW3-0535P RW3-1035P RW3-2035P RW3-3035P

Bath volume (L / cu ft)

5 / 0.2

10 / 0.4

20 / 0.7

30 / 1.1

Working temperature range (℃ / ℉)

-35 to 150 / -31 to 302

Temperature stability 1)  (±℃ / ℉)

0.05 / 0.09

Cooling capacity 2)

(bath fluid: ethanol)

at -20℃ (-4℉), W

80

150

400

440

at 0℃ (+32℉), W

150

330

660

700

at +20℃ (68℉), W

280

450

800

880

Refrigerator

1/2 LBP, R-404A

1/2 LBP, R-404A

3/4 LBP, R-404A

1 LBP, R-404A

Pump

(bath fluid: water)

Max. pressure

5.9 PSI (406.8 millibar)

Max. flow rate

7.4 gallons / minute (28 liters / minute)

Dimension

Bath opening / depth

(W×L, D) (mm / inch)

150x99x160

/ 5.9x3.9x6.3

211x154x180

/ 8.3x6.1x7.1

290x214x200

/ 11.4x 8.4x7.9

300x264x230

/ 11.8x10.4x9.1

Exterior (W×L×H)

(mm / inch)

308x480x733

/ 12.1x18.9x28.9

366x532x780

/ 14.4x20.9x30.7

386x602x825

/ 15.2x23.7x32.5

446x662x895

/ 17.6x26.1x35.2

Net weight (kg / lbs)

38 / 83.8

44 / 97

60 / 132.2

67 / 147.7

Electrical requirements (230V, 60Hz) 12.5A 12.5A 13.5A 14.5A
Cat. No. AAH57741K AAH57751K AAH57761K AAH57771K
Electrical requirements (230V, 50Hz) 12.5A 12.5A 13.5A 14.5A
Cat. No. AAH57742K AAH57752K AAH57762K AAH57772K

1) Technical data according to DIN 12876. (bath fluid : ethanol at -10℃)

2) The cooling capacity is measured under 230V / 60Hz electrical condition.

Test Tube Racks

Highly durable stainless steel test tube racks feature adjustable angle and tube height support without requiring any base plate. You can easily mount and release test tube racks.

Cat. No. Description Insert Capacity of Racks*
AAA44581 for 86 test tubes Ø8mm / Ø0.3˝ CW-20G/P, 30G/P
RW3-2025/P, 2040/P
RW-33025/P, 3040/P
AAA44582 for 86 test tubes Ø10mm / Ø0.4˝
AAA44583 for 58 test tubes Ø12mm / Ø0.5˝
AAA44585 for 32 test tubes Ø16mm / Ø0.6˝
AAA44586 for 19 test tubes Ø25mm / Ø1.0˝ 2ea 3ea
AAA41531 for 50 test tubes Ø8mm / Ø0.3˝ BW-05H
BW-05B
RW3-1025/P
RW3-1040/P
CW3-10/P
AAA41532 for 50 test tubes Ø10mm / Ø0.4˝
AAA41533 for 33 test tubes Ø12mm / Ø0.5˝
AAA41535 for 16 test tubes Ø16mm / Ø0.6˝
AAA41539 for 10 test tubes Ø25mm / Ø1.0˝ 1ea
AAA45551 for 176 test tubes Ø8mm / Ø0.3˝ BW-10H
BW-10B
BW-20H
BW-20B
AAA45552 for 176 test tubes Ø10mm / Ø0.4˝
AAA45554 for 84 test tubes Ø12mm / Ø0.5˝
AAA45556 for 68 test tubes Ø16mm / Ø0.6˝
AAA45561 for 33 test tubes Ø25mm / Ø1.0˝ 1ea 2ea

* No declination.

Spring Wire Racks

Ideal for holding a wide variety of tubes, flasks, and other glassware. All components are made of stainless steel. (for all models)

Spring Wire Racks

Cat. No. Suitable for
AAA51522 CW3-20/P, RW3-2025/P, 2040/P
AAA51523 CW3-30/P, RW3-3025/P, 3040/P


Gateway

Establish Jeio Tech Network by Gateway. No computer use is required at all. Remote monitoring of operating status through a mobile phone is simply available when you place a Gateway in your laboratory. Maximum 4 units can be connected to Gateway by RS-232 cable.

Cat. No. Description Suitable for
AAAQ1011 Gateway (2.4GHz, 100~240V, 50/60Hz) CW3, RW3 models
